6R Cruise Control Retrofit Problems

[ciclo]

Yes.
I suppose in this sale will be included all the wires you'll need, including Trip Computer wires. Ask before buying.

[S0K0L]

Hi all!

I got the stalks and wires from "kufatec" and wires are bit different what I saw somewhere on forum :/

@ciclo I found your pic from your sale, and I put my wires which I get. (maybe difference is because model pre 2012 and after?)



44 (one is for BCM A -braze on, and one with pin is for BCM B)


I figured out why there is few different pins (picture description)

https://www.pdf-archive.com/2017/01/27/ ... -englisch/

In attachment are pictures and Manuals for installing from "Kufatec"

And I didn't get Trip Computer wires and power wire. (I'll buy and make them for Trip Computer just in case if there isn't build in, but don't know what about Power wire? :/ )
Coding is same as in manual for VCDS?

Any advice would be helpful! :/

[iichel]

the one with the red square is a micro quadlock system.

as far as I know, all terminals of the wiring loom are this type (stalks, ECU, BCM).

[ciclo]

A quick study based on your image (sorry ):





Useful link

VCDS

Engine


BCM

[S0K0L]

Thank you ciclo! : )

That's VCDS for Cruise control, and for Trip Computer? :/

Here is the picture of my fuse box it is almost empty xD


Thank you so much for helping me, I red all posts in this topic but it is hard to figured what will be best to do with my wires :/

[ciclo]

viewtopic.php?f=56&t=65096#p489673 (again)



5Amp fuse

Remove fusebox

[S0K0L]

@ciclo

So you suggest to wire 44 fit into slot 10 in Fuse box with 5Amp, and I'll need then this JPT "female" connector for that. Thank you!

I'm sorry about MFD, didn't notice that is on link on previous page in your post

One more time, Thank you! I will start with installing this week, and I hope everything will be 0k! : )

[S0K0L]

Hi everyone!

I didn't install cruise control yet because I had chicken pox :/ Well... better not to have it when you are old :/

Nevermind...
Have one question, at what Nm steering wheel must be tighten? That's one, let say, important thing

[ciclo]

http://workshop-manuals.com/volkswagen/ ... ing_wheel/

[S0K0L]

Hi Ciclo!

Thank you for manuals! But... it is hard connect this wire inside, alot wires around :/ is possibe from front connect over some other existing fuse?

And one more help need, Where can wire for ECU pull inside engine space, cannot find any hole :/ I tried push some firm wire inside where bonnet wire goes but cannot find it inside, don't have space for hand.

Another time I will think if will do something like this again

[ciclo]

For the fuse box:
Look at the images shown in this guide https://drive.google.com/file/d/0B2nv91 ... sp=sharing

For the wire through firewall: (thanks to firegrafik)



Draw your own conclusions and use the workshop manual to remove the required parts.

Another time I will think if will do something like this again

[S0K0L]

Ok!

Wire is installed, I pull it trough hole of wire for bonnet opening, it was tricky but succesful! I'll put pictures another day where exactly

So you tell it is better to install wire somehow in fusebox from behind... hm hm

Thank you, will try!

[S0K0L]

Hi all!

Again me and my problems....

After installing new stalks, and turning car on, everything works on new stalks except first speed wipers!?

Cruise control is not yet installed because I looking for JPT female pin for Fuse Box, The one I bought is not good, a bit small...

Back to the wipers problem, after this conclusion it doesn't work on first speed I installed back old stalks, and after turning car on it was same problem, again first speed not working, well I was a bit scared what did I do now. I looked at fuse box, pressing all fuses to right place and one was not in good position, after that I turned on car again and somehow wipers are working at first speed.

I'm not sure if the problem was in fuse box or problem maybe is in new stalks, maybe car 'pulled' information from new stalks for automatic turn on when rain starts, and when I put back again old stalks, car remembered info from new stalk for automatic turnin on.

After second ignitioning of car, wipers at first speed worked well, but don't know if the problem was in fusebox or the car 'pulled' back old information for old stalks? :/

I'll put again new stalks tomorrow and will see if the problem will be the same. :/

Very confusing situation for me, but as I'm a always bad luck man, didn't expect it will goneverything well with this installation

Yes, sorry for bad english

Cheers!!

[iichel]

the stalks are purely mechanical, they don't have a brain or a memory. 1st position is the 'automatic' setting, if you have the rain sensor

[ciclo]

Hi all!

Again me and my problems....

After installing new stalks, and turning car on, everything works on new stalks except first speed wipers!?

Only the first wiper speed? ...

T41 a common fail, perhaps too common...
